0.8 Mm CO2 Mig Welding Wire Er70s-6 Er50-6 15kg

Product Details:
Place of Origin: CHINA
Brand Name: LONGTENG
Certification: TUV CE, ABS, DB, ISO9001
Model Number: ER70S-6
Payment & Shipping Terms:
Minimum Order Quantity: one pallet
Price: USD 1
Packaging Details: Neutral box/ LT color box/OEM brand box
Delivery Time: 15 WORKING DAYS
Supply Ability: 1,200,000 TON PER YEAR

Detail Information

Product Name: Cooper Cotaed Welding Wire ER70S-6 Model: ER70S-6
Brand: LONGTENG Diameter: 0.8/0.9/1.0/1.2/1.6mm
Weight: 5kg/15kg/20kg/250/350kg Surface: Cooper Plating
Spool Material: Black Plastic Spool/steel Packing: Color Box/bucket
OEM: Accept Diameter Of Spool: 100/200/270/300mm
High Light:

Er70s6 Mig Wire

,

0.8 Mm CO2 Mig Welding Wire Er70s-6

,

CO2 Mig Welding Wire Er70s-6 15kg

Product Description

 CO2 Mig Welding Wire Er70s-6 Gas Shielded

LT*ER70S-6 0.8/1.0/1.2/1.6mm Cooper Coating Welding Wire



MIG welding wire AWS A5.18 ER70S-6,is a kind of carbon steel shielded welding wire. The melting speed of welding wire is fast when welding. It has stable arc, low spatters and beautiful appearance. Good corrosion-resistant on surface of base material. Decrease the probability of blowhole formation. All position welding has good performance CO2 or Ar+CO2 can be used as shielded gas.



LT·ER50-6 Conform to Standard :



GB/T 8110 ER50-6

ISO 14341-A-G424C13Si1

AWS A5.18 ER70S-6

JIS YGW12



Main Characteristics:
1. Low welding costs.
2. High productivity and low electricity consumption.
3. Easy to operate. All-position welding.
4. Very low hydrogen content in the weld and lower nitrogen content. Excellent crack-resistance.
5. Little deformation after welding.
6. Wide applicability. Suitable for welding thin, medium and thick plates.



Application:
AWS A5.18 ER70S-6
1. Used for welding all kinds of 500MPa structural steel parts.
2. Used for welding all kinds of 500MPa plates and pipes.



Chemical Composition(%)

Chemical Composition C Mn Si S P Ni Cr Mo V Cu
Guarantee Value 0.06~0.15 1.40~1.85 0.80~1.15 ≤0.025 ≤0.025 ≤0.15 ≤0.15 ≤0.15 ≤0.03 ≤0.50
General Result 0.077 1.45 0.87 0.013 0.012 0.017 0.031 0.002 0.004 0.125



Mechanical Properties of Deposited Metal
Test Item Rm(MPa) ReL/Rp0.2(MPa) A(%) KV2(J)
-40℃
Guarantee Value ≥500 ≥420 ≥22 ≥47
General Result 555 450 29 77/95/83

Reference Current(DC+)
Size(mm) Current range (A) GAS flow rate(L/min)
Φ0.8 50~100 15
Φ1.0 50~220 15~20
Φ1.2 80~350 15~25
Φ1.6 170~550 20~25
