CO2 Copper Coated Mig Welding Wire 1.6mm 1.2mm 1.0mm GMAW SV08G2S

Minimum Order Quantity : one pallet Price : USD 1
Packaging Details : Neutral box/ LT color box/OEM brand box Delivery Time : 15 WORKING DAYS
Supply Ability : 1,200,000 TON PER YEAR
Place of Origin: CHINA Brand Name: LONGTENG
Certification: TUV CE, ABS, DB, ISO9001 Model Number: GMAW SV08G2S (AWS A5.18 ER70S-6)

Detail Information

Product Name: CO2 Gas Shielded Welding Wire ER70S-6 Model: GMAW SV08G2S
Brand: LONGTENG Diameter: 0.8/0.9/1.0/1.2/1.6mm
Weight: 1/5/15/20kg Surface: Cooper Plating
Spool Material: Black Plastic Spool Packing: Color Box
OEM: Accept Diameter Of Spool: 100/200/270/300mm
High Light:

CO2 Copper Coated Mig Welding Wire 1.6mm

,

Mig Welding Wire 1.6mm GMAW SV08G2S

,

CO2 Copper Coated Welding Wire GMAW SV08G2S

Product Description

GMAW LT*SV08G2S 0.8/1.0/1.2/1.6mm Cooper Coating Welding Wire

GMAW LT·SV08G2S Conform to Standard :

GB/T 8110 ER50-6

ISO 14341-A-G424C13Si1

AWS A5.18 ER70S-6

JIS YGW12



GMAW SV08G2S  is a mild steel welding wire that contains higher levels of manganese and silicon than other standard grades of MIG wire to produce high quality welds when used on dirty, oily, or rusty steel. The high silicon content increases the fluidity of the weld pool, thus creating a smoother bead appearance and resulting in minimal post-weld grinding. This wire is engineered to provide porosity-free, x-ray quality welds at the highest tensile strength (as welded) of all the plain carbon steel wires. This product requires a shielding gas: CO 2 and/or CO 2 mix



Purpose:

1. Used for welding all kinds of 500MPa structural steel parts.

2. Used for welding all kinds of 500MPa plates and pipes



Chemical Composition(%)

Chemical Composition C Mn Si S P Ni Cr Mo V Cu
Guarantee Value 0.06~0.15 1.40~1.85 0.80~1.15 ≤0.025 ≤0.025 ≤0.15 ≤0.15 ≤0.15 ≤0.03 ≤0.50
General Result 0.077 1.45 0.87 0.013 0.012 0.017 0.031 0.002 0.004 0.125





Mechanical Properties of Deposited Metal

Test Item Rm(MPa) ReL/Rp0.2(MPa) A(%) KV2(J)
-40℃
Guarantee Value ≥500 ≥420 ≥22 ≥47
General Result 555 450 29 77/95/83



Reference Current(DC+)
Size(mm) Current range (A) GAS flow rate(L/min)
Φ0.8 50~100 15
Φ1.0 50~220 15~20
Φ1.2 80~350 15~25
Φ1.6 170~550 20~25
