Vendre des électrodes de soudage par point chaud en acier doux Baguette de soudure AWS E6013 pour les marchés africains

Minimum Order Quantity : 1 Ton Price : USD 1
Packaging Details : Neutral box/ LT Color box/OEM brand box Delivery Time : 15 WORKING DAYS
Payment Terms : L/C, D/P, T/T Supply Ability : 1,200,000 TON PER YEAR
Place of Origin: CHINA Brand Name: LONGTENG
Certification: TUV CE, ABS, DB, ISO9001,CCS Model Number: J421 E6013

Product Description

Product Description


E6013 2.0/2.5/3.2/4.0/5.0 mm Carbon Steel Electrodes


E6013 is a mild-steel, all position, general purpose cellulose-base rod. It operates on AC or DC welding current and works well on low voltage AC machines. E6013 is an excellent choice where there is poor fit-up in the joint. It deposits easily and smoothly producing medium to shallow penetration. Small sizes are well adapted to low heat on thin metals. Medium to heavy slag is easily removed and provides for excellent weld cleaning action during the welding process.


Conform to Standard

GB/T 5117 E4313

AWS A5.1 E6013

ISO 2560-B-E 43 13 A

Purpose:It is suitable for welding structures made of low carbon steel, performs very well in welding thin and small size steel plates and also has very good performance in the situation that requires nice and clean bead appearance.


Specification:J421 is rutile-based carbon steel electrode. It has very good welding usability that enables it to perform all-position welding, operates on AC/DC, removal of slag is easy, has stable arc and also has very good bead appearance. It is easy to operate, which makes re-striking the arc easy.


Chemical Composition(%)

Chemical Composition C Mn Si S P Ni Cr Mo V
Guarantee Value




≤0.035 ≤0.040





General Result 0.075 0.38 0.21 0.018 0.024 0.020 0.032 0.005 0.010



Mechanical Properties of Deposited Metal

Test Item Rm(MPa) ReL(MPa) A(%) KV2(J)
Guarantee Value ≥430 ≥330 ≥16 ≥47
General Result 485 380 28.5 86


X-Ray Radio-graphic Test Requirements:Grade II

Reference Current(AC,DC)

Diameter(mm) Φ2.0 Φ2.5 Φ3.2 Φ4.0 Φ5.0
Amperage(A) 40~70 50~90 90~130 130~210 170~230
